| battery model |
voltage |
capacity |
dimension(mm) |
assembly figure |
terminal |
reference weight(kgs) |
| v |
ah |
l |
w |
h |
battery |
electrolyte |
| 6n4-bs |
6 |
4 |
71 |
71 |
88 |
 |
/ |
0.65 |
0.20 |
| 6n6-bs |
6 |
6 |
98 |
56 |
110 |
 |
b |
0.90 |
0.30 |
| yb2.5l-bs |
12 |
2.5 |
81 |
71 |
105 |
 |
/ |
1.10 |
0.26 |
| yb3l-bs |
12 |
3 |
100 |
58 |
105 |
 |
b |
1.10 |
0.30 |
| ytx4l-bs |
12 |
3 |
114 |
71 |
86 |
 |
a |
1.10 |
0.30 |
| ytx5l-bs |
12 |
4 |
114 |
71 |
106 |
 |
a |
1.55 |
0.50 |
| 12n5l-bs |
12 |
5 |
120 |
62 |
128 |
 |
b |
1.50 |
0.50 |
| 12n6.5l-bs |
12 |
6.5 |
139 |
73 |
100 |
 |
b |
1.60 |
0.52 |
| ytx7l-bs |
12 |
6 |
114 |
71 |
131 |
 |
a |
2.10 |
0.56 |
| ytx7a-bs |
12 |
6 |
152 |
88 |
94 |
 |
a |
2.00 |
0.56 |
| 12n7a-bs |
12 |
7 |
146 |
59 |
130 |
 |
b |
1.90 |
0.60 |
| 12n9-bs |
12 |
9 |
137 |
77 |
135 |
 |
b |
2.30 |
0.76 |
| ytx9-bs |
12 |
8 |
152 |
88 |
106 |
 |
a |
2.30 |
0.65 |
| ytx10-bs |
12 |
10 |
135 |
90 |
145 |
 |
a |
3.40 |
0.95 |
| ytx12-bs |
12 |
10 |
152 |
88 |
131 |
 |
a |
3.30 |
1.10 | |
|
|
