| jis |
rated voltage
(v) |
capacity |
(-18°c)cca(a) |
maximum overall dimensions(mm) |
without
acid weight
approx (kg) |
| old type |
new type |
c20(ah) |
re(min) |
l |
w |
h |
th |
| n28 |
|
12 |
28 |
42 |
220 |
183 |
115 |
190 |
200 |
6.5 |
| n32 |
36b20(s) |
12 |
32 |
47 |
230 |
197 |
130 |
163 |
193 |
6.8 |
| ns40 |
36b20 |
12 |
36 |
47 |
280 |
198 |
128 |
201 |
221 |
7.5 |
| n40 |
36c24 |
12 |
40 |
59 |
240 |
234 |
127 |
199 |
219 |
8.2 |
| ns60 |
46b24(s) |
12 |
45 |
67 |
280 |
241 |
132 |
182 |
203 |
8.7 |
| n48 |
55b24 |
12 |
48 |
71 |
310 |
234 |
132 |
200 |
222 |
9 |
| n50 |
48d26 |
12 |
50 |
76 |
310 |
261 |
169 |
200 |
221 |
10 |
| n60 |
55d23 |
12 |
60 |
94 |
375 |
261 |
169 |
200 |
221 |
11 |
| n70 |
65d31 |
12 |
70 |
113 |
520 |
309 |
170 |
201 |
225 |
12.5 |
| n70z |
75d31 |
12 |
75 |
123 |
600 |
309 |
170 |
201 |
225 |
13 |
| n80 |
95d31 |
12 |
80 |
133 |
600 |
305 |
170 |
200 |
222 |
13.5 |
| n100 |
9.50e 42 |
12 |
100 |
176 |
680 |
404 |
171 |
205 |
229 |
16.5 |
| n100z |
1.05e 43 |
12 |
105 |
187 |
680 |
406 |
172 |
208 |
230 |
16.5 |
| n110 |
1.30e 43 |
12 |
110 |
194 |
680 |
432 |
169 |
209 |
231 |
18 |
| n115 |
115f51 |
12 |
115 |
202 |
720 |
501 |
156 |
205 |
228 |
18 |
| n120 |
145f51 |
12 |
120 |
223 |
720 |
506 |
180 |
209 |
232 |
20 |
| ns150 |
145g51 |
12 |
135 |
260 |
850 |
499 |
180 |
212 |
259 |
24.5 |
| n150 |
145g51 |
12 |
150 |
300 |
850 |
507 |
221 |
212 |
234 |
24.5 |
| n165 |
165g51 |
12 |
165 |
342 |
850 |
505 |
221 |
212 |
258 |
26 |
| n200 |
190h52 |
12 |
200 |
441 |
1020 |
506 |
264 |
215 |
235 |
30 |
| n220 |
245h52 |
12 |
220 |
460 |
1020 |
513 |
264 |
211 |
259 |
31 | |
|
|
